Metabolic Measurement System, Vista MX Mixing Chamber, Silver Edition (#17590)

Description

Vista MX Mixing Chamber Type Metabolic Measurement System, 2-year Warranty (#17590)

We guarantee +/-3% accuracy of the VO₂ and VCO₂ measurements!

Vista-MX is a complete metabolic measurement system for Cardio-Pulmonary Exercise Stress (VO2 and VCO2) and Resting Energy Expenditure (REE) testing. It may be used as a portable desktop system with your own computer, or with your choice of integrated mobile carts, including an “IBM-compatible” computer and Super-VGA high resolution monitor.

The basic Vista-MX includes O2 and CO2 gas analyzers, permanently calibrated turbine ventilation meter, a USB interface with our “TurboFit” software and either a mouthpiece or face mask interface. All you need to add is a PC.

Mixing chamber not shown

Specifications

• Electro-chemical fuel cell O2 sensor and infra-red CO2 sensor.(Gold Edition uses paramagnetic O2 sensor)
• Flow Sensor: Permanently calibrated turbine. Accuracy: +/- 2%. Optional low-flow sensor for pediatric measurements.
• Nafion permanent dryer
• USB Plug-and-Play PC interface
• External Inputs: ECG/Heartrate digital and analog Heart Rate interface imports heart rate from any Polar watch (optional)RS232 ports for treadmill and/or ergometer control
• Size/Weight: 35.5 cm W, 9.5 cm H, 35 cm D, 10 pounds

Other Options

• Blood pressure module with SpO2 option
• Computer controlled ergometer
• Computer, monitor, printer
• Computer controlled treadmill
• EtCO2 module
• Mobile carts (Click on “Other Options” above)
• 12-lead ECG
